31

LIGHTWEIGHT QUARTER SHAFTS SOLID BEARING SPACERS QUARTER SHAFT TAB WASHER REAR AXLE
High grade steel, top quality reproduction of Made from high grade steel with extra Standard item.
the original made to our CAD drawings. length in order to be ground to length on JRAX102A All each £1-95
Optimised for the lightest weight. Supplied assembly to avoid using shims in the most
with our own top quality driveshaft studs demanding applications. DRIVE SHAFT BOLTS
ready fitted. JCRAX105 Series I each £17-50 High quality bolts with stepped diameter
shank to locate into the flange. Made to our
JCRAX160AS Series 1 each £220-00 JCRAX106 Series III each £17-50 specification.
JCRAX160S Series 3 each £220-00
QUARTER SHAFT NUT JRAX170B 1.98" UHL each £6-25
NOTE: Our Series1 shafts require Series 3 Reproduction of the original metric thread
metric bearing retaining nuts. item. HEAVY DUTY DRIVE SHAFT NUTS
JRAX162 Series III each £8-95 All metal stiff nuts.
716SNNF each £1-25

COMPLETE AXLES
We have considerable experience in building both complete
assembled differentials and complete axle units.
We can build these to your chosen specification.
For axle cradles please see page 34.
