TORSION BAR REACTION PLATE It is necessary to order the comprehensive SUSPENSION
Our Torsion Bar Reaction Plate system for Fitting Kit separately which consists of
the Jaguar E-Types is a greatly improved aircraft quality nuts and bolts, including 4
replacement over the original, with a new Noggin pairs to allow adjustment, with a
design which is considerably lighter and up further 16 Noggin pairs available in the
to four times stronger than others currently Extra Noggin Kit, allowing the ride height to
on the market. A fresh approach was taken be adjusted in /16" increments.
3
using CAD and Finite Element Analysis
(FEA) to produce this off the shelf kit which JCSUF130P/E 15.980" £185-00
makes it straight forward for easy JCSUF130P/A 16.000" £185-00
adjustment to accurately and professionally JCSUF130P/F 16.032" £185-00
achieve the desired ride height. The JCSUF130P/G 16.045" £185-00
Reaction Plate is made from top quality JCSUF130P/B 16.062" £185-00
steel and has been heat treated for extra JCSUF130P/C 16.085" £185-00
strength. For ease of installation and to JCSUF130P/D 16.100" £185-00
guarantee the end user a better fitting JCSUF130P/H 16.125" £185-00
component, due to the many varying car JCSUF130P/I 16.156" £185-00
widths the Reaction Plate is available in JCSUF130P/J 16.186" £185-00
FITTING KIT different torsion bar centre widths. JCSUF130P/K 16.218" £185-00
Comprehensive aircraft quality nut, bolt and NOTE
washer set. Including 4 Noggin pairs. Extra sizes constantly being added. Contact
JCSUF130 Set £109-50 us for an instruction leaflet explaining the
easiest way to measure your torsion bar
EXTRA NOGGIN KIT centre distance prior to ordering.
16 Noggin pairs in addition to those
supplied in the fitting kit. Then allowing a
full range.
JCSUF130N £159-95
COMPETITION TORSION BARS
0.900" Diameter and hollow for full race
applications.
JCSUF122 Pair £631-80

Denis & Jeremy Welch finish 2nd overall in the 3 hour
Autosport race Snetterton 2014. Race trophies were
presented by Marcus Pye and Jack Sears.
Photo: Charlie Wooding
