Large square brakes COMPETITION BRAKE PADS. BRAKES
Available in a variety of compounds, bonded
to a thick steel backing plate 63mm square.
LARGE Mk IX CALLIPER BODIES. COMPETITION PISTON ASSEMBLIES JCBRK164D/5 DS2500 - Fast road £124-00
Newly manufactured by ourselves to suit – LARGE JCBRK164D/P1 RS14 - Fast road £195-00
the large 63mm square pads. Made from Aluminium bodies with stainless steel JCBRK164D/3 DS1-11 - Sprint/race £152-94
our own pattern equipment using the best pistons and modern seals to suit the large JCBRK164D/9 RS29 - Long distance race £195-00
grade cast iron to achieve minimal 63mm square calliper body. These help JCBRK164D/P2 RS19 - Long distance race £195-00
distortion under heavy braking. reduce the heat sink and reduce piston pull JCBRK164D/P3 RSL-1 - Long distance race £195-00
The fronts have 4.875” bolt centres and are back. Must be used with brake pads which
now available in two different offsets. have thick steel backing plates. PAD RETAINER
Reproduction of standard.
JCBRK420B is a direct reproduction of the Available with different piston diameters to
MkIX calliper to fit a std E-Type upright suit front and rear. JCBRK430 each £8-97
using the adaptor bracket JCBRK410 which Alternative piston diameters available to REAR CALLIPER MOUNTING BRACKET.
matches a 12.125” disc or is a direct fit to a order. Aluminium brackets to mount the large rear
LWE upright with 11.500” disc JCBRK401A 2.125” Piston Assemblies calliper to the standard 1/4 shaft housing
1
JCBRK420L has offset bolt centres to bolt Front each £125-00 bolts of a SRl to suit the 11 /4" diameter disc
directly to a LWE upright and 12.125” disc. JCBRK201A 1.625” Piston Assemblies – JCBRK 220D
The rear bodies are the same large size and Rear each £125-00 JCBRK210 each £80-00
accept the same 63mm square size brake Replacement parts
pads incorporating the handbrake calliper JCBRK402A 2.125" Piston each £17-38
mounting lugs with 4 /2” bolt centres. JCBRK402B 1.625" Piston each £17-38
1
JCBRK158 2.125" Seal each £4-30
JCBRK420L Front LWE upright each £395-00
NEW
Product JCBRK161 1.625" Seal each £7-62
JCBRK420B Front standard upright each £395-00
JCBRK220LB Rear LH each £495-00 ARP BOLTS
JCBRK220RB Rear RH each £495-00 Top quality bolts to hold the calliper bodies
on and reduced diameter heads to hold on
FRONT CALLIPER MOUNTING BRACKETS. the piston assemblies.
Aluminium brackets to mount the Mk IX
Dunlop calliper on a standard Jaguar JCBRK420AB 5/16" Bolt each £2-00
upright with 3” bolt centres, thus allowing JCBRK420W 5/16" Washer each £0-60 For SR3 or magnesium axles with rear
the use of the 12.125” diameter disc, JCBRK420CB 1/2" x 1.25" Bolt each £3-95 calliper mounts integral with the 1/4 shaft
JCBRK151 or JCBRK 152. JCENG420LB 1/2" X 2.5" Bolt each £6-50 housing we have a range of new housings
SENG561W 1/2" Washer each £1-45 available, see page 30.
JCBRK410 each £75-00
