FALSE REGULATORS ALTERNATOR PULLEYS 3-D PRINTING ELECTRICAL
Ideal when fitting any kind of alternator Aluminium, machined from billet. To suit a As part of our quest to improve the quality
conversion. Keeps the original bulkhead 1 /2” wide fan belt with a 15 mm diameter of our products and manufacture, we have
look and makes it easy to join the wires, hole, these fit both our Lucas ACR or Denso invested in a 3-D printing machine.
with the benefit of an internal fuse. alternators. When we design a product (usually with the
CELG163 2 bobbin screw each £39-95 XPCELG169 2 /2” (64mm diameter) £15-80 help of original factory drawings) it’s often
1
CELG163A 2 bobbin spade each £39-95 CELG169PA 3 /2" (90mm diameter) £19-84 helpful to have a 3-D model to see how it
1
CELG164 3 bobbin spade each £39-95
LIGHTWEIGHT ALUMINIUM DYNAMO fits with other components. CAD drawings
Replacement parts PULLEY can only do so much when mating
CELG163F40 40 Amp Fuse each £3-95 Cast in aluminium, these pulleys have a
CELG163F50 50 Amp Fuse each £3-95 components to older ones.
deeper groove to stop the fan belt jumping
LUCAS ALTERNATOR off at high revs and the larger diameter This prototyping device helps us in
Lucas 36 and 45 amp output 17 ACR type. slows down the speed to stop the windings perfecting the fit and also helps us see if
Inc 2 /2"(64mm) diameter /2" wide pulley & from over heating. improvements can be made. In the case of
1
1
fan. CELG187 C45 dynamo 17mm hole £49-50 items that need a casting pattern, we can
also develop these with this technique
CELG169 Outright sale 36 amp £79-00 CELG187L C40/C42 dynamo 15mm hole £59-50 meaning costs are reduced.
CELG169B Outright sale 45 amp £89-00
Our competitors often manufacture by
Replacement parts
Alternator no fan or pulley EXCHANGE copying the ‘last one in the parts bin’ and this
CELG169A 36 amp £59-00 leads to ‘tooling creep’ meaning that parts
CELG169C 45 amp £69-00 grow or shrink as each batch is made,
leading to assembly problems. At Denis
RACE ALTERNATOR
Brand new Denso design. Upgraded for Welch Motorsport we manufacture only from
high performance & reliability in the UK two tolerenced drawings so this cannot happen.
outputs available, both in the same size
case. Ultra lightweight at 2.5 Kg. Supplied
without pulley.
YCELG169R 40 amp £186-00
YCELG169S 90 amp £530-00
NYLON ADJUSTER STRAP
We have developed this adjuster strap to
eliminate the problem of the steel one
breaking due to vibration. This can be used
on all models, dynamo or alternator.
CELG172 £9-95
